Description
ZM10 W is suitable for processing straight-line edge & 45°arrises on glass.
Enkong Glass Machinery specialized in making high-quality glass machine, glass edging machine for global customers.
waterproof glass machinery high precision series
Brand name:
Enkong
Place of origin:
Guangdong China
Certificate:
CE/ISO(CSA UL certificate can be customized according to customer requirement for the production)
Minimum order:
1 set
Price term:
FOB/CIF/C&F(optional)
Payment terms:
L/C, T/T
Package detail:
package with film
Delivery:
20-45days
Enterprise Strength
- Enkong provides practical and solution-oriented services based on customer demand.
Product Comparison
Enkong carries out strict quality monitoring and cost control on each production link of glass edging machine, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.glass edging machine has the following advantages over other products in the same category.
-
v s
1. Every ingredient of Enkong glass straight line edging machine has undergone a strict antimicrobial effectiveness test and is scientifically assessed by our professional QC team.
2. By virtue of its unique treatment process, the safety and effectiveness of glass machinery are at a cutting-edge of the industry.
3. The product has been recognized with ISO 9001 certification.
4. This product helps man to reduce his or her job. And because of this, the money that is required to pay is totally reduced.
5. Using this product means less human error. It can perform repetitive tasks and is less likely to make mistakes than an employee.
/ General description
Description
A special design of the in-feed section for controlling the grinding amount of glass without adjusting each spindle individually.
Description
Indepent wool felt wheel and the cerium water recirculation system make the flat edge more shining.
Description
With ABB spindle motors and the conveyor system running on ball bearing units, this machine has a much stronger loading and delivering capacity, thus it is able to process mini piece and extremely thick piece with high precision and good water-proofing.
Description
Input and output conveyors adopt timing belt which can improve the stability of transmission.
Description
Speed is adjusted by frequency inverter; PLC with pneumatic polishing.
/ Technical Date
Technical Data
◆ Spindles: 10pcs
◆ Processing glass thickness: 3-25mm
◆ Angle of arris: 45°
◆ Min.size of glass: 40mm×40mm
◆ Processing speed: 0.5~5m/min
◆ Dimension: 7820×1400×2500mm
◆ Processing glass thickness: 3-25mm
◆ Angle of arris: 45°
◆ Min.size of glass: 40mm×40mm
◆ Processing speed: 0.5~5m/min
◆ Dimension: 7820×1400×2500mm
/ producy detials
Operation Condition
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
/ Wheels Disposal
6 spindles for the straight-line edge (adopt the independent wool felt wheel)
2 spindles for front and back arris each.
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features
1. With a renowned ability in developing and manufacturing glass straight line edging machine, Guangdong Enkong Machinery Co.,Ltd. has stood firmly in the fierce domestic markets.
2. Our company takes pride in investing in a wide range of production facilities. These facilities are highly efficient and allow us to produce products complying with the highest standards.
3. Accurately grasping the pulse of the times, Enkong concentrates on the innovation development to be more competitive in the market. Inquire! Enkong always keeps customers' needs in first place. Inquire!
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Our Services
Remarks
1. All the electrical elements, Circuit breaker protection and AC contactors are schneider or other world famous brand.
2. International CE standard high flexibility, high shielding cables.
3. Warranty time: 1 year
4. Quotation Valid: 90 days
5. Payment terms: 30%T/T as deposit, 70% balance made before shipment by T/T
6. Delivery time: 30 days upon receipt of 30% deposit by T/T
7. After sales service:
1)24 hours service on Internet and Telephone, free instructions and problem solving
2) Free training to make sure a master of the operating of cnc router for the person who come to our factory
3)User-friendly English manual or operating video for machine using and maintaining
4) on-the-spot training, installation and repairing can be met if required.
