Enkong Glass Machinery specialized in making high-quality glass machine, glass edging machine for global customers.
Enkong with ABB spindle motors glass machinery factory direct supply
1. Regarding the quality management of Enkong glass straight line edging machine, it is demanded to pass through the extremely harsh quality control and inspection required for gift and crafts.
2. This product is non-toxic. The materials and parts used in it have been tested to guarantee no harmful element is contained.
3. The product stands out for its durability. Its housing features strong shock resistance to allow inner circuit boards to work well even in bad condition.
4. Due to its high accuracy levels, the product can improve production achievement whilst also reducing the time needed for quality control.
ZM10 W is suitable for processing straight-line edge & 45°arrises on glass.
A special design of the in-feed section for controlling the grinding amount of glass without adjusting each spindle individually.
Indepent wool felt wheel and the cerium water recirculation system make the flat edge more shining.
With ABB spindle motors and the conveyor system running on ball bearing units, this machine has a much stronger loading and delivering capacity, thus it is able to process mini piece and extremely thick piece with high precision and good water-proofing.
Input and output conveyors adopt timing belt which can improve the stability of transmission.
Speed is adjusted by frequency inverter; PLC with pneumatic polishing.
Technical Data
◆ Processing glass thickness: 3-25mm
◆ Angle of arris: 45°
◆ Min.size of glass: 40mm×40mm
◆ Processing speed: 0.5~5m/min
◆ Dimension: 7820×1400×2500mm
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
6 spindles for the straight-line edge (adopt the independent wool felt wheel)
2 spindles for front and back arris each.
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features
1. Guangdong Enkong Machinery Co.,Ltd. is greatly appreciated in a variety of different markets throughout the world because of the strong ability in manufacturing glass machinery.
2. We adopt world-advanced technology when manufacturing glass machinery.
3. We attach great importance to sustainable development. We challenge our factories to adopt cleaner and more efficient operations to produce less waste and reduce our environmental footprint. Our goal is to design and produce the most professional, safest, most advanced and environmentally friendly products. We will attach more importance to R&D in the future to increase our innovative level and creativity. We have demonstrated sound environmental practices for many years. We have been focused on carbon footprint reductions and product end-of-life recycling.
If you are window fabricator, looking for new machine for business expansion,
If you have interest to set up window production line as your new business,
Or you have any questions about window machine,
All the parts of machine can do some changes to meet your requirements. Any details information or help you want, please contact with me.
- WhatsApp: 0086-13589148572
- Skype: freeman2599
- WeChat: 13589148572
CCI team is here, ready for support. press "send", let's start !
CCI produce high quality machines, also pay attention to package. The machines will be packed with standard export wooden case, to make sure customer will receive the machines they ordered Intact.
As an innovator of glass machine, ENKONG will continue to pursue further development from a higher perspective, to set an example to the glass machine industry and build up an everlasting brand!
Professional glass processing machinery manufacturer and international glass equipment exporter.
