Enkong Glass Machinery specialized in making high-quality glass machine, glass edging machine for global customers.

Wholesale double glazing glass machine zm10w company for processing glass 1
Wholesale double glazing glass machine zm10w company for processing glass 2
Wholesale double glazing glass machine zm10w company for processing glass 3
Wholesale double glazing glass machine zm10w company for processing glass 4
Wholesale double glazing glass machine zm10w company for processing glass 5
Wholesale double glazing glass machine zm10w company for processing glass 1
Wholesale double glazing glass machine zm10w company for processing glass 2
Wholesale double glazing glass machine zm10w company for processing glass 3
Wholesale double glazing glass machine zm10w company for processing glass 4
Wholesale double glazing glass machine zm10w company for processing glass 5

Wholesale double glazing glass machine zm10w company for processing glass

Brand name:
Enkong
Place of origin:
Guangdong China
Certificate:
CE/ISO(CSA UL certificate can be customized according to customer requirement for the production)
Minimum order:
1 set
Price term:
FOB/CIF/C&F(optional)
Payment terms:
L/C, T/T
Package detail:
package with film
Delivery:
20-45days
Inquiry
Company Advantages
1. Enkong has been tested for guaranteed safety. It has passed the electric strength test, also known as high-voltage insulation test under different rated voltage conditions. Our glass machinery mainly include Glass Edging Machine, Glass Washing Machine and Glass Drilling Machine
2. One of the focusing point in Enkong is to check every detail of the double glazing glass machine . Our machines can be customized according to customer's requirement
3. The product has enough hardness. The main body adopts high performance composite fiberglass material, which is made by hand-made paste. Our products is energy-saving and easy to operate
4. The product has the advantage of corrosion resistance. It is less affected by environmental factors such as air and water. CE certificate is available for all our glass processing machines
5. The product is compatible with a variety of writing styles including continuous strokes, cursive scripts, and word-for-word writing. English and Chinese instruction manual are available for our high quality glass machinery
/  General description

undefined


undefined
Description

ZM10 W is suitable for processing straight-line edge & 45°arrises on glass.

undefined
Description

A special design of the in-feed section for controlling the grinding amount of glass without adjusting each spindle individually.

undefined
Description

Indepent wool felt wheel and the cerium water recirculation system make the flat edge more shining.

undefined
Description

With ABB spindle motors and the conveyor system running on ball bearing units, this machine has a much stronger loading and delivering capacity, thus it is able to process mini piece and extremely thick piece with high precision and good water-proofing.

undefined
Description

Input and output conveyors adopt timing belt which can improve the stability of transmission.

undefined
Description

Speed is adjusted by frequency inverter; PLC with pneumatic polishing.

/  Technical Date
undefined

Technical Data

◆ Spindles: 10pcs
◆ Processing glass thickness: 3-25mm
◆ Angle of arris: 45°
◆ Min.size of glass: 40mm×40mm
◆ Processing speed: 0.5~5m/min
◆ Dimension: 7820×1400×2500mm
/  producy detials
Operation Condition

Power supply: AC220V, 380V, 415V ±10%  3φ  50Hz/60Hz±2%
Environment: Temperature: 1~40℃


undefined
undefined
undefined
/  Wheels Disposal

6 spindles for the straight-line edge (adopt the independent wool felt wheel)
2 spindles for front and back arris each.


undefined


★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.




Company Features
1. Guangdong Enkong Machinery Co.,Ltd. has a mature product research and development team for double glazing glass machine .
2. By centering on the strategic objective of developing Enkong into a international brand, each employee is passionate about work. Please contact us!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
no data

As an innovator of glass machine, ENKONG will continue to pursue further development from a higher perspective, to set an example to the glass machine industry and build up an everlasting brand!

Professional glass processing machinery manufacturer and international glass equipment exporter.
