Company Advantages1. Enkong is designed by leveraging the skills of an advanced development and production team. The working efficiency of our products is high
2. The product can easily finish the heavy-duty work which man can never do. This will definitely increase productivity and relieve workers' stress. All of the machines have a warranty of one year
3. This product meets international industry quality standards. CE certificate is available for all our
glass processing machines4. Reliability: Quality inspection is throughout the whole production, removing all defects effectively and greatly ensuring the consistent quality of the product. Our machines are safe enough to operate
5. To ensure product quality, the product is produced under the supervision of our experienced quality assurance team. All our machines are especially designed for high precision
/ Technical Date
Model
SM2615/25/30/40
Thickness
3--19mm
Glass width
250-1700/300-2700/300-3200/300-4200
Transmission speed
1-15m/min
Parallel tolerance
≤0.2mm/m
Diagonal tolerance
≤0.5mm/m
Arris width
1-5mm
Max.grinding removal of flat edge for each side
3mm
Width opening speed
2m/min(≤ 2500mm width);4m/min(≥3000mm width)
Transmission speed
1-18m/min
Rotation for motor
NO.1-NO.3 using 4200rpm/min;NO.4-9 using frequency conversion;No.10-12 using 1400rpm/min.
Polishing system
Cylinder(Standard)/ Automatic pneumatic polishing(Option)
Installtion power
About 65kw
Weight
About 8000kgs/8500kgs/9000kgs/9500kgs
/ General description
Description
Suitable for high polish demanded products, such as household appliances and furniture.
Description
Machine body and components especial stable design for low vibration processing and ensure tolerance of the diagonal within 0.1 in 1m^2.
![Enkong Top small glass edge polishing machine for business for round edge processing1 9]()
![Enkong Top small glass edge polishing machine for business for round edge processing1 10]()
/ Operation Condition
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features1. Guangdong Enkong Machinery Co.,Ltd. has created a modern production line with a rigorous, serious and sincere attitude.
2. Our consistent pursuit lies in high quality small
glass edge polishing machine for every customer. Inquire now!
