Company Advantages1. Enkong double edger is designed by mechanical drawing. Its structure, shape, dimension, operating principles, and other manufacturing requirements can be all achieved by the precise and high efficient mechanical drawing. All of the machines have a warranty of one year
2. Enkong guarantees the safe delivery for our professional service. Our machines are safe enough to operate
3. Its quality is effectively controlled with the help of our advanced production equipment. CE certificate is available for all our
glass processing machines4. The product has passed the quality and performance tests conducted by the third party assigned by the clients. Our products is energy-saving and easy to operate
/ General description
![undefined]( "undefined")
SM 22 adopted auto-polish feeding senor, optimizing polish level.
Suitable for high polish demanded products, such as household appliances and furniture.
Machine body and components especial stable design for low vibration processing and ensure tolerance of the diagonal within 0.1 in 1m^2.
/ Technical Date
Technical Date
◆ Number of Spindles: 20 (optional: 22 spindles with Low E deletion device, Extra-polish, Servo tracking Safety Corner Cutting)
◆Max. glass dimension: Up to 4200
◆ Min. glass size: 300x300 (optional: 250x250)
◆ Glass thickness: 3~25 mm
◆ Working Speed: 0.5-12 8m/mins
◆Width adjustment Speed: 2m/mins (optional:8m/mins)
◆Max. edge grinding: 1~3 mm
◆Tolerance of the diagonal(1000x1000): ±0.5mm
◆ Tolerance on the parallelism(mm): ±0.3mm
◆Total power: 68 KW
/ producy detials
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
![Enkong Custom double edger for business for round edge processing 9]()
![Enkong Custom double edger for business for round edge processing 10]()
![Enkong Custom double edger for business for round edge processing 11]()
![Enkong Custom double edger for business for round edge processing 12]()
/ Wheels Disposal
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features1. The quality of double edger is stable over the years.
2. We have implemented a sustainability process in our factory. We have decreased energy consumption by investing in new technologies and more efficient facilities.
