Company Advantages1. Whatever you need pattern designed by Guangdong Enkong Machinery Co.,Ltd. or your own pattern, it will be no problem. All our machines are especially designed for high precision
2. The product, with great commercial value, has a promising market application prospect. Our machines can be customized according to customer's requirement
3. It is characterized by its remarkable temperature resistance. High-temperature oxidation resistant coating, which may react with the active molecule under high temperature, is applied on the surface. English and Chinese instruction manual are available for our high quality
glass machinery4. The product will maintain its original room temperature physical properties such as elongation, memory, tensile and hardness at higher and lower temperatures. We have perfect after-sale service for our products
/ Technical Date
Model
SM1015/20/25/30/40
Thickness
3--12mm
Glass width
250-1700/300-2200/300-2700/300-3200/300-4200mm
Transmission speed
1-25m/min
Parallel tolerance
≤0.2mm/m
Diagonal tolerance
≤0.5mm/m
Arris width
1-3mm
Max.grinding removal of flat edge for each side
1.5mm
Width opening speed
16m/min
Transmission speed
1-25m/min
Rotation for motor
NO.1-NO.3 using 4200rpm/min;NO.4-5 using frequency conversion;
Installtion power
about 36kw
Weight
about 5000/5500/6000/6500/7000kgs
/ General description
Production speed of 1-25m/min
Width opening speed of 16m/min
For constructoin glass
![undefined undefined]()
![Enkong cost-effective double edger machine series for household appliances 5]()
/ Operation Condition
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
