Company Advantages1. The working efficiency of our products is high. As one of the unique feature, glass double edger successfully makes
double glass machine more popular among customers. The working efficiency of our products is high
2. Guangdong Enkong Machinery Co.,Ltd., well-known for its superior quality, will provide first-class service. All our machines are especially designed for high precision
3. Patented glass double edger makes it simple to set the correct tension. You can just double glass machine. Our products have wide applications.
4. double edger provides user friendly experience through ergonomic design and equipment. The processing speed of our machines is adjustable.
5. Our machines feature high precision and low operating cost. The production practice shows that double edger machine,glass double edger is warmly welcome by double glass machine because of glass double edger.
/ General description
![undefined]( "undefined")
SM 20 adopted auto-polish feeding senor, optimizing polish level.
Suitable for high polish demanded products, such as household appliances and furniture.
Machine body and components especial stable design for low vibration processing and ensure tolerance of the diagonal within 0.1 in 1m^2.
/ Technical Date
Technical Date
◆ Number of Spindles: 20 (optional: 22 spindles with Low E deletion device, Extra-polish, Servo tracking Safety Corner Cutting)
◆ Max. glass dimension: Up to 4200
◆ Min. glass size: 300x300 (optional: 250x250)
◆ Glass thickness: 3~25 mm
◆ Working Speed: 0.5-12 8m/mins
◆ Dimension: 7820×1400×2500mm
◆ Width adjustment Speed: 2m/mins (optional:8m/mins)
◆ Max. edge grinding: 1~3 mm
◆Tolerance of the diagonal(1000x1000): ±0.5mm
◆ Tolerance on the parallelism(mm): ±0.3mm
◆Total power: 68 KW
/ producy detials
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
/ Wheels Disposal
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features1. There is strict testing for quality of double edger to make satisfying products for customers.
2. Our double edger machine have been well sold to all over the world known as its glass double edger. Inquire online!
