Enkong Glass Machinery specialized in making high-quality glass machine, glass edging machine for global customers.

Enkong Best double edger supply for round edge processing 1
Enkong Best double edger supply for round edge processing 2
Enkong Best double edger supply for round edge processing 3
Enkong Best double edger supply for round edge processing 4
Enkong Best double edger supply for round edge processing 5
Enkong Best double edger supply for round edge processing 6
Enkong Best double edger supply for round edge processing 1
Enkong Best double edger supply for round edge processing 2
Enkong Best double edger supply for round edge processing 3
Enkong Best double edger supply for round edge processing 4
Enkong Best double edger supply for round edge processing 5
Enkong Best double edger supply for round edge processing 6

Enkong Best double edger supply for round edge processing

Brand name:
Enkong
Place of origin:
Guangdong China
Certificate:
CE/ISO(CSA UL certificate can be customized according to customer requirement for the production)
Minimum order:
1 set
Price term:
FOB/CIF/C&F(optional)
Payment terms:
L/C, T/T
Package detail:
package with film
Delivery:
20-45days
Inquiry
Company Advantages
1. The design of Enkong is scientific. It is the application of mathematics, kinematics, mechanics of materials, mechanical technology of metals, etc. Our products have wide applications
2. This product brings an increase in accuracy and repeatability. As it is programmed to perform a task over and over again, the accuracy and repeatability compared to an employee is far greater. Our machines are safe enough to operate
3. The product can withstand the stress from the body. The Achilles tendon protector reduces stress on the Achilles tendon by locking the shoe around the heel. CE certificate is available for all our glass processing machines
/  TECHNICAL DATE

SM20 High-tech series Technical parameter(For Furniture glass)


  • Model
    SM2615/25/30/40
  • Thickness
    3--19mm
  • Glass width
    250-1700/300-2700/300-3200/300-4200
  • Transmission speed
    1-15m/min
  • Parallel tolerance
    ≤0.2mm/m
  • Diagonal tolerance
    ≤0.5mm/m
  • Arris width
    1-5mm
  • Max.grinding removal of flat edge for each side
    3mm
  • Width opening speed
    2m/min(≤ 2500mm width);4m/min(≥3000mm width)
  • Transmission speed
    1-18m/min
  • Rotation for motor
    NO.1-NO.3 using 4200rpm/min;NO.4-9 using frequency conversion;No.10-12 using 1400rpm/min.
  • Polishing system
    Cylinder(Standard)/ Automatic pneumatic polishing(Option)
  • Installtion power
    About 65kw
  • Weight
    About 8000kgs/8500kgs/9000kgs/9500kgs
/  GENERAL DESCRIPTION


SM 26 adopted auto-polish feeding senor, optimizing polish level, secondary transmission.

Suitable for high polish demanded products, such as household appliances and furniture.

Machine body and components especial stable design for low vibration processing and ensure tolerance of the diagonal within 0.1 in 1m^2.


Operation Condition


Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%

Environment: Temperature: 1~40℃

★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
