Company Advantages1. glass double edging machine is of judgmatical design and reliable operation. All of the machines have a warranty of one year
2. We have strict inspection system to control quality when producing glass double edging machine. The processing speed of our machines is adjustable
3. It has satisfactory durability and serviceability. The fabric and weaving techniques are chosen based on the particular end use of this product. Our products are of high quality with great functions
4. This product is watertight and meets the International Standard for waterproofing. Its waterproof membrane or coating will prevent water droplets from penetrating through the fabric. The performance and operation of our products are stable
5. The product runs stably and reliably. It is not prone to the effects of sudden surges, susceptibility driven, gaps, interruptions, and voltage variations. Our products has high performance in glass processing
/ General description
![undefined]( "undefined")
SM 20 adopted auto-polish feeding senor, optimizing polish level.
Suitable for high polish demanded products, such as household appliances and furniture.
Machine body and components especial stable design for low vibration processing and ensure tolerance of the diagonal within 0.1 in 1m^2.
/ Technical Date
Technical Date
◆ Number of Spindles: 20 (optional: 22 spindles with Low E deletion device, Extra-polish, Servo tracking Safety Corner Cutting)
◆ Max. glass dimension: Up to 4200
◆ Min. glass size: 300x300 (optional: 250x250)
◆ Glass thickness: 3~25 mm
◆ Working Speed: 0.5-12 8m/mins
◆ Dimension: 7820×1400×2500mm
◆ Width adjustment Speed: 2m/mins (optional:8m/mins)
◆ Max. edge grinding: 1~3 mm
◆Tolerance of the diagonal(1000x1000): ±0.5mm
◆ Tolerance on the parallelism(mm): ±0.3mm
◆Total power: 68 KW
/ producy detials
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
/ Wheels Disposal
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features1. Guangdong Enkong Machinery Co.,Ltd. provides the less expensive and more cost-effective glass double edging machine to fulfill each customer needs.
2. The quality of our double edger machine still keeps unsurpassed in China.
3. Under the monitoring of new media and activist groups, the company strives to minimize environmental impacts and reduce resources waste. These movements help it to establish a good business reputation in society. Inquiry!
