Company Advantages1. The manufacturing process of Enkong glass double edger is well-conducted by a professional production team. The processing speed of our machines is adjustable
2. With this product, less work is required to be done by human labor, which enhances speed, accuracy, and efficiency. CE certificate is available for all our
glass processing machines3. The product performance has been greatly improved by our innovative R&D team. All of the machines have a warranty of one year
/ General description
![undefined]( "undefined")
SM 20 adopted auto-polish feeding senor, optimizing polish level.
Suitable for high polish demanded products, such as household appliances and furniture.
Machine body and components especial stable design for low vibration processing and ensure tolerance of the diagonal within 0.1 in 1m^2.
/ Technical Date
Technical Date
◆ Number of Spindles: 20 (optional: 22 spindles with Low E deletion device, Extra-polish, Servo tracking Safety Corner Cutting)
◆ Max. glass dimension: Up to 4200
◆ Min. glass size: 300x300 (optional: 250x250)
◆ Glass thickness: 3~25 mm
◆ Working Speed: 0.5-12 8m/mins
◆ Dimension: 7820×1400×2500mm
◆ Width adjustment Speed: 2m/mins (optional:8m/mins)
◆ Max. edge grinding: 1~3 mm
◆Tolerance of the diagonal(1000x1000): ±0.5mm
◆ Tolerance on the parallelism(mm): ±0.3mm
◆Total power: 68 KW
/ producy detials
Power supply: AC220V, 380V, 415V ±10% 3φ 50Hz/60Hz±2%
Environment: Temperature: 1~40℃
/ Wheels Disposal
★ Products order can be made according to customer’s request. Our company reserves the right to renew and revise as well as cease the technology depending on design requirements.
Company Features1. Enkong's own R&D department enables us to meet our customers' professional customization needs.
2. Guangdong Enkong Machinery Co.,Ltd. will firmly grasp the corporate positioning of the main force for in glass double edger field. Call now!
